ZKTeco ZKB102S 1D CCD Barcode Scanner

Physical Parameters

Dimensions (L*W*H): 167.3*70.5*81.5 (mm)

Weight: 120g

Voltage & Current: 5 VDC Operating: 120mA (Standby: 30mA)

Color: Black and Gray (White, optional)

Support Host Interface: USB ( RS-232, optional)

User Indicators: Decode LED Indicator; Beeper (adjustable tone and volume)

Performance Parameters

Scan Mode: Manual Reading Mode

Light Source: 620nm Red light

Scan Speed: 50ms/time

Minimum Print Contrast: 25%

Roll Tolerance: ±30°

Pitch Tolerance: ±60°

Skew Tolerance: ±60°

Decode Capability: 1D : UPC-A, UPC-E, EAN-8, EAN-13, ISSN, ISBN, Code 128, ISBT 128, Code 39, Code 93, Code 11,Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5 (IATA), Codabar (NW-7)

Environmental Parameters

Operating Temperature: -20°C to 50°C

Storage Temperature: -40°C to 70°C

Humidity: 5% to 95% relative humidity, non-condensing

Electrostatic Discharge (ESD): ±2KV Direct; ±8KV Air

Ambient Light Immunity: 10000 Lux Max

Decode Ranges

Symbology / Resolution: Near/Far

Code 39: 4 mil:  3 cm to 10 cm

Code 39: 5 mil: 3 cm to 13 cm

Code 39: 13 mil: 4 cm to 30 cm

EAN-13: 13 mil: 3 cm to 30 cm

UPC-A: 13 mil: 3 cm to 30 cm
