Gigabyte AMD Chipset A520M DS3H Micro-ATX AMD AM4 Motherboard

Name: Gigabyte AMD Chipset A520M DS3H Micro-ATX AMD AM4 Motherboard
Brand: GIGABYTE
SKU: 11532
Price: 10500.00 BDT
Availability: InStock

No reviews yet

In stock

COD available

Delivery 1 Day

Return Policy Based

Return support is available for valid issues after delivery. Please keep packaging and invoice.

৳10,500.00 /pc

3 available

Minimum order qty 1

QTY

Delivery & Payment

Delivery across Bangladesh within 24 to 72 hours in most cases.
Cash on delivery is available for this product on eligible orders.
Safe and secure payment options.

Return & Support

Return support is available for valid issues according to the return policy.
Keep the product, accessories, invoice, and packaging for faster support review.
Shop One support helps with delivery, return, and order follow-up.

Buyer-first checkout Review price, delivery, and payment option before confirming the order.

Order proof kept Your order history and invoice help support resolve issues faster.

Deals You Can't Miss

Product Overview

Everything you need to know before placing the order.

Buyer-first details

Basic Information
Brand	Gigabyte
Model	Gigabyte A520M DS3H
Supported CPU	AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Chipset	AMD A520
BIOS	1 x 128 Mbit flash
	Use of licensed AMI UEFI BIOS
	PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Audio	Realtek ALC887 codec
	High Definition Audio
	2/4/5.1/7.1-channel

Expansion Slots
PCI	CPU:
	1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
	Chipset:
	2 x PCI Express x1 slots, supporting PCIe 3.0 (PCIEX1_1, PCIEX1_2)
M.2 Socket	1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
M.2 Socket
Graphics:
Graphics	1 x DisplayPort, supporting a maximum resolution of 5120×2880@60 Hz
	1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz
	1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
	Support for up to 3 displays at the same time
Max Shared Memory	16 GB

Connector & Ports:
HDMI	1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
Display Port (s)	1 x DisplayPort, supporting a maximum resolution of 5120×2880@60 Hz
DVI-D (s)	1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz
USB (s)	CPU:
	4 x USB 3.2 Gen 1 ports on the back panel
	Chipset:
	2 x USB 3.2 Gen 1 ports available through the internal USB header
	4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
LAN Port (s)	Realtek GbE LAN chip (1000 Mbit/100 Mbit)
Supported Storage	CPU:
	1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
	Chipset:
	4 x SATA 6Gb/s connectors
	Support for RAID 0, RAID 1, and RAID 10
Audio	Realtek ALC887 codec
	High Definition Audio
	2/4/5.1/7.1-channel
Internal I/O Ports	1 x 24-pin ATX main power connector
	1 x 8-pin ATX 12V power connector
	1 x CPU fan header
	2 x system fan headers
	1 x addressable LED strip headers
	1 x RGB LED strip headers
	1 x M.2 Socket 3 connectors
	4 x SATA 6Gb/s connectors
	1 x front panel header
	1 x front panel audio header
	1 x USB 3.2 Gen 1 header
	1 x USB 2.0/1.1 headers
	1 x serial port header
	1 x Q-Flash Plus button
	1 x Clear CMOS jumper
TPM (Trusted Platform Module )	1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)

Memory:
Type	Dual-Channel Architecture
Slots	4 x DDR4 DIMM
Supported Memory	3rd Gen AMD Ryzen Processors:
	Support for DDR4 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
	3rd Gen AMD Ryzen with Radeon Graphics processors:
	Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
	Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
	Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
	Support for Extreme Memory Profile (XMP) memory modules
Maximum Memory	128 GB (32 GB single DIMM capacity)

Others:
Special Features	Support for APP Center
	Support for Q-Flash
	Support for Q-Flash Plus
Bundled Software	Support for Windows 10 64-bit
Bundled Software	Support for Windows 10 64-bit
Warranty Info
Years	3 Year
