Product Overview
Everything you need to know before placing the order.
Buyer-first details
| Model | CS-X5S-R100-8W |
|---|---|
| IPC Access Capability | |
| Wireless/Wired IPC Access Capability | 3K *8 |
| Wired IPC Access Capability | 3K *8 (X5S-8W) |
| Network Parameters | |
| Antenna Number | 2 |
| Max Wireless Range | 100m |
| Radio Frequency | 2.4G |
| Ethernet Port | One 10/100M adaptable Ethernet interface |
| Required Access Bandwidth | 50 Mbps/100 Mbps |
| Video Output | |
| VGA | 1 channel (identical to HDMI output) resolution up to 1920*1080/60Hz |
| HDMI | 1 channel resolution up to 2592*1944/30HZ |
| Audio/Video Codec | |
| Recording Resolution | 3K / 2K+ / 2K / 1080p / UXGA / 720p / VGA / 4CIF / 2CIF / CIF / QCIF |
| Video Encoding | H.265, H.264 |
| Decode Playback | Supports 8*3K |
| Video Recording Management | |
| Video Recording Mode | Manual video recording; Motion detection recording; Scheduled video recording; Event triggered recording |
| Backup Mode | Hard disk backup, Internet application backup |
| Playback Mode | Instant playback ; Normal playback ; Event playback ; Tag playback; Log event playback |
| Open Protocol | |
| Open Protocol Support | HIKVISION, ONVIF (V.2.5) |
| HDD | |
| Interface Type | One built-in SATA port |
| Capability | Supports 1TB to 8TB 3.5-inch HDD |
| External Interface | |
| Audio Input/ Output | Not support |
| Hardware Reset | Supports |
| USB2.0 Interface | 2 |
| Dimensions | |
| Product Dimensions | 235 × 270 × 44.5 mm (9.25 × 10.6 × 1.75 inch) |
| Packaging Dimensions | 387 × 362 × 75 mm (15.2 × 14.3 × 3 inch) |
| Power Supply | |
| DC | 12V/1.5A |
| Consumption | |
| Standby status | ≤8W |
| Weight | |
| Net Weight | 932 g |
More Information:
Name: Moktadiur Rahman
Mobile: +8801708-488749
Email: moktadiur.rahman@Shop One
Terms & conditions
Order, delivery and return notes.
- Delivery across Bangladesh usually takes 24 to 72 hours depending on location, courier flow, and stock readiness.
- Cash on delivery orders require no advance payment. Please inspect the parcel during delivery before final acceptance.
- For return support, keep the product, accessories, and packaging in saleable condition and contact Shop One support quickly after delivery.
Questions
Short answers before checkout.
Is EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs available with cash on delivery in Bangladesh?
EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs is available with cash on delivery on eligible orders in Bangladesh. No advance payment is needed before delivery.
How long does delivery take for EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs?
Delivery across Bangladesh usually takes 24 to 72 hours depending on stock and courier coverage.
Can I return EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs if I do not like it after delivery?
If the product is not the right fit, contact Shop One support quickly after delivery and keep the product, accessories, and packaging in saleable condition for return review.
Which category does EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs belong to?
EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs is listed under Security Devices on Shop One. You can explore similar products from the same category for easier comparison.
Which brand makes EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs?
EZVIZ CS-X5S 8CH Wireless NVR with HDMI & VGA Outputs is listed under the brand Ezviz on Shop One.
